SIGNA EXCITE 1.5T – 8 CHANNEL
| Specification | Parameter |
|---|---|
| No. of Channels | 8 |
| Software Versions | 11X |
| Type Of Magnet | CXK-4 |
| Helium Boiloff | Zero Boiloff |
| Magnet Weight | 5300kg |
| Diameter | 60CM |
| FOV | 48CM |
| Gradient Amplitude | 33mT/m |
| Slew Rate | 120mT/sec |
| Special Application | GRE, SPGRE, FGRE, FSPGR, MRCP / 2d cine Angiography LAVA, Propellar. Tricks |
| Recommended | 10-15 cases |
SIGNA HD 1.5T
| Specification | Parameter |
|---|---|
| No. of Channels | 8, 16 |
| Software Versions | 12X |
| Type Of Magnet | CXK-4 |
| Helium Boiloff | Zero Boiloff |
| Magnet Weight | 5300kg |
| Diameter | 60CM |
| FOV | 48CM |
| Slew Rate | 120mT/sec |
| Special Application | GRE, SPGRE, FGRE, FSPGR, MRCP / 2d cine Angiography LAVA, Propellar. Tricks, DTI, Enhance, Inhance |
| Recommended | 15-25 cases |
SIGNA HDxT 1.5T – 16 CHANNEL
| Specification | Parameter |
|---|---|
| No. of Channels | 8, 16 |
| Software Versions | 12X |
| Type Of Magnet | CXK-4 |
| Helium Boiloff | Zero Boiloff |
| Magnet Weight | 5300kg |
| Diameter | 60CM |
| FOV | 48CM |
| Gradient Amplitude | 33mT/m |
| Slew Rate | 120mT/sec |
| Special Application | LAVA, Propeller, Cube T2 Tricks, IDEAL, Enhance, SWAN, Perfusion, Non-contrast, Angiom, DTI, probe – 2000 |
| Recommended | Below 20-30 Cases |
